Vehicle Exploded View - MOTO-GUZZI DAYTONA 1000 Daytona Racing 1000 1996
:format(webp)/p2r-public-documents.s3.eu-west-3.amazonaws.com/maker/motoguzzi.svg)
Chassis : 33.17 ROUE ARRIÈRE
/p2r-public-documents.s3.eu-west-3.amazonaws.com/eclate/486/Daytona_Racing_1000_1996_33.17.PNG)
:format(webp)/p2r-public-documents.s3.eu-west-3.amazonaws.com/ref/1/3/2/4/0/2/img/132402.jpg)
2 |
ROULEMENT DE ROUE (20X47X14) ORIGINE PIAGGIO COMMUN A LA GAMME MOTO-GUZZI -GU92204220- More informationQuantity required : 2 |
||||||
4 |
GU37634505 - BAGUE More informationQuantity required : 1 |
||||||
:format(webp)/p2r-public-documents.s3.eu-west-3.amazonaws.com/ref/6/7/3/3/2/img/67332.jpg)
6 |
SCREW - (8X25) FOR CALIPER OR SHOCK ABSORBER "PIAGGIO GENUINE PART" COMMON TO THE RANGE -597150- More informationQuantity required : 8 |
||||||
:format(webp)/p2r-public-documents.s3.eu-west-3.amazonaws.com/ref/7/3/4/4/8/img/73448.jpg)
7 |
WASHER (8,4X13X0,8) "PIAGGIO GENUINE PART" COMMON TO ALL THE RANGE MOTO-GUZZI -GU14615901- More informationQuantity required : 8 |
||||||
|
8 |
GU37634405 - BAGUE More informationQuantity required : 5 |
||||||
:format(webp)/p2r-public-documents.s3.eu-west-3.amazonaws.com/ref/1/3/0/8/6/8/img/130868.jpg)
10 |
SCREW - REAR DISC BRAKE FASTENING "PIAGGIO GENUINE PART" COMMON TO THE RANGE MOTO-GUZZI -GU30611460- More informationQuantity required : 5 |
||||||
|
11 |
GU37633305 - AXE DE ROUE AR More informationQuantity required : 1 |
||||||
|
12 |
GU37634105 - ENTRETOISE INTERNE D. More informationQuantity required : 1 |
||||||
:format(webp)/p2r-public-documents.s3.eu-west-3.amazonaws.com/ref/1/3/1/8/6/8/img/131868.jpg)
13 |
SPACER- FOR REAR WHEEL "PIAGGIO GENUINE PART" MOTO-GUZZI 1000 DAYTONA, V10, 1100 SPORT -GU37634805- More informationQuantity required : 1 |
||||||
:format(webp)/p2r-public-documents.s3.eu-west-3.amazonaws.com/ref/1/3/0/6/5/4/img/130654.jpg)
14 |
GU30217900 - RONDELLE 13X18X1,7 More informationQuantity required : 1 |
||||||
|
15 |
GU30632601 - VIS FIX.AXE More informationQuantity required : 1 |
||||||
|
16 |
GU28617760 - SOUPAPE AIR More informationQuantity required : 1 |
||||||
|
17 |
GU14616150 - CONTREPOIDS More informationQuantity required : 1 |
||||||
|
18 |
GU31619865 - PLAQUE MOTO GUZZI More informationQuantity required : 1 |
